Die Casting Quality Checklist: 10 Critical Points for Incoming Inspection

What to check first

Incoming inspection is your last line of defense before a defective die casting part reaches machining, assembly, or final assembly. A structured die casting quality checklist keeps your team focused on the defects that matter most. The goal is not to find every microscopic blemish. It is to catch the defects that will stop a process, trigger a supplier return, or create a safety risk.

Start with the paperwork. Match the packing list to the purchase order. Verify the part number, revision level, and quantity. Check the heat traceability record. For aluminum and magnesium parts, the mill certificate confirms the alloy composition and the heat number. Without that record, you cannot trace the material back to the melt shop if a problem appears later.

Next, do a visual sweep. Lay the parts out on a light table or a well-lit inspection bench. Look for obvious damage first. Shipping containers crush corners and bend thin walls. Forklift tines leave dents. Tape and strapping marks can scratch the surface. These issues are not casting defects, but they affect finish and fit.

Dimensions and critical features

Measure the critical dimensions. Do not measure every feature on the drawing. Pick the features that control fit, function, and stacking. For a drive shaft housing, that might be the bore diameter, the mounting flange thickness, and the face runout. For a connector bracket, it might be the hole position and the tab width.

Use the gauge blocks and CMMs that match the supplier’s inspection method. If the supplier uses a CMM and you use a caliper, the readings can differ by a few thousandths. Agree on the method before the first article. Record the measurement method in your checklist.

Check the critical features in both directions. A part may be in tolerance on the first lot and drift on the second. Measure the first, middle, and last part in each shipment. A drift pattern is a red flag. It suggests the die is wearing, the shot pressure is changing, or the melt temperature is unstable.

Surface finish and cosmetic defects

Surface finish is a common cause of customer complaints. Inspect the parts for the defects that affect appearance and corrosion resistance. Zinc die castings often have a bright gray finish. Aluminum parts have a duller gray or a zinc chromate tint. The color should be consistent across the batch.

Look for sand inclusions. These appear as small, rough spots that catch light differently. They are usually caused by sand from the mold or from the part being handled. Look for gas porosity. These are small, smooth, blind cavities, often under the surface. They are harder to see than sand inclusions and more dangerous because they can grow under pressure.

Check for flash. Flash is thin material that leaks between the mold halves. It looks like a thin lip around the part. Small amounts are normal. Large or uneven flash suggests mold wear, high shot pressure, or poor venting. Flash is easy to remove, but it signals a process problem that will return.

Porosity and internal defects

Porosity is the most common quality issue in die casting. It comes in two main forms. Gas porosity is trapped air or hydrogen from the melt. Shrinkage porosity is a void that forms as the metal solidifies and pulls back from the mold wall. Both create weak spots in the part.

For incoming inspection, you are not doing destructive testing. You are looking for evidence that porosity is present. Look for dark spots on the surface. These can be gas pockets that broke through. Look for rough, pitted areas. These can be shrinkage cavities. If you have a magnetic particle inspection tool, use it on ferrous parts. It will show surface cracks and near-surface porosity.

Red flag: parts with a pitted finish that are not uniform. If the pits are only on the high-stress areas, the die may be out of balance. If they are random, the melt may have too much gas. Both problems require a supplier response.

Gating and parting marks

Gating marks are the spots where the sprue and runner attach to the part. They are normal, but they should be consistent. If the gating marks are large, uneven, or in the same location on every part, the die may be worn. If they are in different locations, the parting line may be shifting.

Check the parting line. It is the thin line where the two mold halves meet. It should be sharp and consistent. A rough or thick parting line means the mold is not closing properly. It can also mean the parting line is not clean. Oil or debris on the parting line creates a rough finish and can trap porosity.

Material and heat traceability

Verify the material. For aluminum die castings, the most common alloys are A380 and A383. For zinc, the most common are ZADC and ZA. The alloy affects the strength, corrosion resistance, and finish. If the supplier substitutes an alloy without telling you, the part may not pass your mechanical tests.

Check the heat traceability. The heat number is stamped on the part or written on the packing list. It links the part to the melt shop record. If you receive a part without a heat number, reject it. You cannot verify the composition. If the heat number is there but the composition is off, reject it. The part may not meet your mechanical requirements.

Documentation and supplier records

The checklist is only as good as the documentation. Keep a record of every inspection. Include the part number, date, inspector name, and the results of each check. Photograph defects. Note the location on the part. Use a scale or a reference object in the photo.

For each shipment, keep the mill certificate, the inspection report, and the packing list together. If a problem appears in the field, you need to know which heat was used and what the incoming inspection found. This record supports your corrective action request to the supplier.

Common mistakes in incoming inspection

The most common mistake is measuring too many features. It slows down the inspection and increases the chance of human error. Focus on the critical features. The drawing should mark them. If it does not, ask the supplier to identify them.

Another mistake is relying on one inspector. Different people see different things. Rotate inspectors for the same part. Calibrate them regularly. If two inspectors disagree on a defect, discuss it. The goal is consistency, not agreement.

A third mistake is accepting a part because it is close to tolerance. If the drawing says 10.00 plus or minus 0.05, a part at 10.049 is in tolerance. It is not a problem. If it is 10.051, it is out of tolerance. Do not negotiate with the drawing. The drawing is the requirement.

When to reject a part

Reject a part if it fails a critical dimension. Reject it if it has a defect that affects function or safety. Reject it if the material is wrong or the heat traceability is missing. Reject it if the surface finish is out of specification.

Do not reject a part for a cosmetic defect that does not affect function. A small scratch on a non-visible surface is not a problem. A scratch on a visible surface is a problem. Your specification defines what is acceptable. Use it. If the specification is vague, write it down before the next shipment.

Sample checklist for incoming inspection

Use this checklist for each shipment. Print it or use it as a template in your quality system.

1. Verify the packing list matches the purchase order.
2. Check the part number, revision level, and quantity.
3. Review the heat traceability record and mill certificate.
4. Measure the critical dimensions.
5. Check the surface finish for sand inclusions, gas porosity, and shrinkage porosity.
6. Look for flash and gating marks.
7. Check the parting line for sharpness and consistency.
8. Verify the material alloy.
9. Photograph any defects.
10. Record the findings and sign the checklist.

Red flags to watch for

• Parts with a pitted or rough finish that is not uniform.
• Flash that is large or uneven.
• Gating marks that are large or in the same location on every part.
• Parts without a heat number.
• A drift in critical dimensions across the shipment.
• A surface color that is different from previous batches.

If you see any of these, stop the shipment. Do not put the parts in production. Call the supplier. Send the photos and the checklist. Ask for a root cause analysis. Do not accept the parts until the supplier confirms the problem is fixed.

Final thoughts

Incoming inspection is a practical process. It is not about finding every defect. It is about catching the defects that will cause problems later. A good die casting quality checklist keeps your team focused and consistent. It gives you the data you need to hold your suppliers accountable and keep your production running. Start with the critical features. Check the porosity. Verify the material. Keep the paperwork together. Do that, and you will reduce scrap and rework.
